Specifications

Capacity Tons 5 10 20 30 50 75 100 150 200 250 315
Area of Bolster L-RxF-B 350x300 435x350 500x375 600x400 625x475 700x550 900x600 1000x700 1150x800 1200x850 1350x950
Distance Between Bed of Ram (SUAU) 210 280 300 360 400 425 455 500 550 600 700
Slide Stroke Length Adjustable or Fix 40 50 65 85 100 110 125 125 150 150 175
Adjustment of Slide 25 25 28 30 35 40 45 50 60 70 75
Shank Hole 25 28 30 35 40 45 50 55 63 65 70
No. of Slide Strokes 55 50 50 45 45 40 40 35 30 30 25
Main Motor 1/1440 2/1440 2/1440 3/1440 5/1440 7.5/1440 10/1440 15/1440 20/1440 25/1440 30/1440
Motor Pulley Dia B-2.5 B-3 B-3 B-4 B-5 B-6 B-7 B-7 C-8 C-8 C-9
Height from Floor to top ok Bolster 625 325 675 700 725 750 775 825 825 825 850
Bed Openind (Dia) 75 100 100 125 150 175 200 225 250 275 300
Req.air pressure for pneumatic clutch ( Kg/Cm2) 5.5 5.5 5.5 5.5 5.5 5.5 5.5 5.5 5.5 5.5 5.5
Capacity - 1.6 1.6 3.0 5.0 7.5 10.0 15.0 20.0 25.0 30
Stroke Length - 25 25 45 65 75 85 100 110 110 120
Air Pressure (Kg/Cm2) 5 5 5 5 5 5 5 5 5 5 5
