Specifications

Capacity Tons 20 30 50 75 100 150 200 250 300 400 500
Area of Bolster L-RxF-B 400x400 437x462 435x512 525x600 575x625 650x750 800x850 850x900 925x950 1025x1050 1100x1100
Distance Between Bed of Ram (SUAU) 275 300 350 375 400 450 500 550 600 650 700
Slide Stroke Length (Adjustable) 65 85 100 110 125 125 150 150 175 200 200
Adjustment of Slide 28 30 35 40 45 50 60 70 75 85 90
Shank Hole 30 35 40 45 50 55 63 65 65 75 80
No. of Slide Strokes (RPM) 50 45 45 40 40 35 30 30 30 25 25
Main Motor HP/RPM 2/1440 3/1440 5/1440 7.5/1440 10/1440 15/1440 20/1440 25/1440 30/1440 40/1440 50/1440
Motor Pulley Dia (inches) B-4 B-4 B-5 B-6 B-7 B-7 C-8 C-8 C-9 C-9 C-10
Height from Floor to top ok Bolster 650 650 700 725 750 800 825 850 850 875 875
Bed Openind (Dia) 100 125 150 175 200 225 250 275 300 325 325
Req.air pressure for pneumatic clutch ( Kg/Cm2) 5.5 5.5 5.5 5.5 5.5 5.5 5.5 5.5 5.5 5.5 5.5
Capacity 1.6 3.0 5.0 7.0 10.0 15.0 20.0 25.0 30.0 40.0 40.0
Stroke Length 25 45 65 75 85 100 110 110 125 125 125
Air Pressure (Kg/Cm2) 5 5 5 5 5 5 5 5 5 5 5
