Specifications

Capacity in Tons 20 25 80 100 120 140 160
Bending Length x Thickness 1525x1.6 2030x1.6 2540x3 3125x3 2540x6 3125x6 3125x8
Clear Distance & Between Body Piller to Piller 1000 1200 1500 1700 1500 1700 1700
S.P.M. 40 40 35 30 25 25 25
Ram Stroke Length 50 50 75 75 75 75 75
Shut Height (S.D.U.P.) 200 200 250 275 275 275 300
Depth of Throat 180 180 200 200 250 250 250
Stroke Adjustment 40 40 60 60 60 60 75
Main Motor H.P./R.P.M. 5/1440 7.5/1440 10/1440 15/1440 20/1440 25/1440 30/1440
Air Pressure Required (Kg/Cm2) 5.5 5.5 5.5 5.5 5.5 5.5 5.5
