Specifications


Capacity (Cutting
Length x Cutting Capacity )

(Model)
Max Back
Gauge Adjustment
Size of Blades
Blade Segments
Motor H.P./RPM S.P.M.

48"/1220 mm x 3 mm MEW - UC - 03 20 - 500 1250x65x18 5/1440 45
48"/1220 mm x 6 mm MEW - OC - 06 20 - 500 1250x65x20 7.5/1440 45
48"/1220 mm x 12 mm MEW - OC - 012 20 - 500 1250x75x25 10/1440 40
60"/1525 mm x 3 mm MEW - UC - 03 20 - 500 1525x65x18 7.5/1440 45
60"/1525 mm x 6 mm MEW - OC - 06 20 - 500 1525x65x20 10/1440 45
60"/1525 mm x 12 mm MEW - OC - 012 20 - 500 1525x75x25 15/1440 40
72"/1830 mm x 3 mm MEW - UC - 03 20 - 500 1830x65x18 7.0/1440 40
72"/1830 mm x 6 mm MEW - OC - 06 20 - 500 1830x75x20 15/1440 40
72"/1830 mm x 12 mm MEW - OC - 012 20 - 500 1830x75x25 15/1440 30
100"/2540 mm x 3 mm MEW - UC - 03 20 - 600 2540x65x18 10/1440 35
100"/2540 mm x 6 mm MEW - OC - 06 20 - 600 2540x75x20 20/1440 30
100"/2540 mm x 12 mm MEW - OC - 012 20 - 600 2540x100x25 25/1440 25
120"/3040 mm x 3 mm MEW - UC - 03 20 - 600 3040x75x18 15/1440 35
120"/3040 mm x 6 mm MEW - OC - 06 20 - 600 3040x75x25 25/1440 30
120"/3040 mm x 12 mm MEW - OC - 012 20 - 600 3040x100x28 30/1440 25
