Specifications

Capacity ( Tons) 200 200 200 250 250 250 315 315 315
Bolster area L-RxF-B 1500x1200 1800x1200 2500x1300 1500x1000 1800x1200 2500x1300 1500x1000 1800x1200 2500x1300
Slide area L-RxF-B 1400x800 1700x1000 2400x1100 1400x800 1700x1000 2400x1100 1400x800 1700x1000 2400x1000
Stroke length (fix) 200 200 200 200 200 200 200 225 250
Shut height (SDAU) 450 450 450 500 500 550 550 550 550
Day light (SUAU) 650 650 650 700 700 750 750 775 800
Slide Adjustment (motorised) 100 100 100 110 110 125 125 125 125
No. of slide stroke (SPM) 25 20 20 25 20 25 20 20 20
Main Motor (HP) 25 20 25 25 25 30 30 30 40
Req.air pressure for pneumatic clutch ( Kg/Cm2) 5.5 5.5 5.5 5.5 5.5 5.5 5.5 5.5 5.5
  Capacity (Tons) 20 20 20 25 25 25 30 30 30
Stroke Length 110 110 110 110 110 110 110 125 140
Req. Air pressure (Kg/Cm2) 5 5 5 5 5 5 5 5 5
